Hanbell jedinica za srednje do visoke temperature
Hanbell vijčana jedinica za srednje do visoke temperature je visokoučinkovito, integrirano rashladno rješenje posebno dizajnirano za aplikacije srednje do visoke temperature isparavanja. Jedinica naglašava stabilnost sustava, radnu pouzdanost i jednostavnost korištenja u inženjerskim projektima. Sadrži kompaktnu strukturu sve u jednom koja visoko integrira vijčani kompresor, separator ulja, hladnjak ulja, spremnik tekućine, ekonomizator, regulator tlaka i električni upravljački ormarić. Osim toga, opremljen je modularnim okvirom, zapornim ventilima, nepovratnim ventilima, sigurnosnim ventilima i sustavom za ubrizgavanje ulja, isporučujući potpuno funkcionalnu rashladnu jedinicu izravno iz tvornice. Ovaj integrirani dizajn pojednostavljuje instalaciju i puštanje u rad na licu mjesta, poboljšavajući učinkovitost projekta.
Jedinica je sveobuhvatno konfigurirana, sa svim glavnim rashladnim komponentama i kontrolnim elementima od renomiranih marki kako bi se osigurao koordinirani rad između komponenti, povećavajući ukupnu pouzdanost sustava i radnu sigurnost. Modularni dizajn okvira pruža fleksibilnost za buduća proširenja ili održavanje, smanjujući ukupnu složenost rada i održavanja dok osigurava dosljednu izvedbu u uvjetima srednje do visoke temperature.
Uvod u parametre opreme
Prikaz detalja
Kontaktirajte nas
Uvod u parametre opreme
| Model jedinice | Kom.Model | Com, Cuartity | Kondenzirajući temp. (℃) | Temp. isparavanja (℃) | Rezervoar (L) | Opskrba cijev (mm) | Usisavanje cijev (mm) | Gas Outiet cijev (mm) | tekućina ulazna cijev (mm) | Dimenzija (mm) (DxŠ×V) | |||||||||
| -15 | -10 | -5 | 0 | 5 | |||||||||||||||
| Kapacitet hlađenja/ulazna snaga (kw) | |||||||||||||||||||
| LXPL-BHF-30M | RC2-100B -Z (30KS) | 1 | 35 | 47. | 18.7 | 38.1 | 19.4 | 70.6 | 20.1 | 85.2 | 20.7 | 101.2 | 21.2 | 80 | Φ28 | Φ54 | Φ42 | Φ35 | 1700×900×1100 |
| 40 | 43.8 | 20.4 | 34.1 | 21.2 | 66.4 | 22.0 | 80.3 | 22.7 | 96.4 | 23.3 | |||||||||
| 45 | 40.3 | 22.2 | 50.0 | 23.1 | 61.6 | 24.0 | 74.8 | 24.8 | 90.4 | 25.3 | |||||||||
| LXPL-BHF2 -60M | RC2-100B -ZP (30KS) | 2 | 35 | 94.2 | 37.4 | 116.2 | 38.8 | 141.2 | 40.2 | 170.4 | 41.4 | 202.4 | 42.4 | 100 | Φ35 | Φ89 | Φ54 | Φ35 | 2300×1700×1800 |
| 40 | 87.6 | 40.8 | 108.2 | 42.4 | 132.8 | 44.0 | 160.6 | 45.4 | 192.8 | 46.6 | |||||||||
| 45 | 80.6 | 44.4 | 100.0 | 46.2 | 123.2 | 48.0 | 149.6 | 49.6 | 180.8 | 50.6 | |||||||||
| LXPL-BHF3 -90M | 3 | 35 | 141.3 | 56.1 | 174.3 | 58.2 | 211.8 | 60.3 | 255.6 | 62.1 | 306.3 | 63.6 | 150 | Φ42 | Φ89×2 | Φ54 | Φ42 | 3000×1700×1800 | |
| 40 | 131.4 | 61.2 | 162.3 | 63.6 | 1992 | 66.0 | 240.9 | 68.1 | 289.2 | 69.9 | |||||||||
| 45 | 120.9 | 66.6 | 150.0 | 69.3 | 184.8 | 72.0 | 224.4 | 74.4 | 271.2 | 75.9 | |||||||||
| LXPL-BHF4 -120 milijuna | 4 | 35 | 188.4 | 74.8 | 232.4 | 77.6 | 282.4 | 80.4 | 340.8 | 82.8 | 408.4 | 84.8 | 200 | Φ57 | Φ108 ×2 | Φ108 | Φ76 | 3700×1700×1800 | |
| 40 | 1752 | 81.6 | 216.4 | 84.8 | 265.6 | 88.0 | 321.2 | 90.8 | 385.6 | 93.2 | |||||||||
| 45 | 161.2 | 88.8 | 200.0 | 92.4 | 246.4 | 96.0 | 299.2 | 99.2 | 361.6 | 101.2 | |||||||||
| LXPL-HF -40M | RC2-140B -Z (40KS) | 1 | 35 | 65.1 | 24.4 | 80.2 | 25.4 | 97.6 | 26.3 | 117.8 | 271.0 | 141.0 | 27.8 | 80 | Φ28 | Φ54 | Φ42 | Φ35 | 1730×700×1100 |
| 40 | 60.7 | 26.6 | 74.9 | 27.7 | 91.7 | 28.7 | 110.9 | 29.6 | 133.2 | 30.4 | |||||||||
| 45 | 55.9 | 29.1 | 69.3 | 30.3 | 85.2 | 31.4 | 103.4 | 32.5 | 124.9 | 33.4 | |||||||||
| LXPL-BHF2 -80M | RC2-140B -ZP (40KS) | 2 | 35 | 130.2 | 48.8 | 160.4 | 50.8 | 1952 | 52.6 | 235.6 | 54.2 | 282.0 | 55.6 | 150 | Φ35 | Φ108 | Φ54 | Φ35 | 2300×1700×1800 |
| 40 | 121.4 | 53.2 | 149.8 | 55.4 | 183.4 | 57.4 | 221.8 | 59.2 | 266.4 | 60.8 | |||||||||
| 45 | 111.8 | 58.2 | 138.6 | 60.6 | 170.4 | 62.8 | 206.8 | 65.0 | 249.8 | 66.8 | |||||||||
| LXPL-BHF3 -120 milijuna | 3 | 35 | 195.3 | 73.2 | 240.6 | 76.2 | 292.8 | 78.9 | 353.4 | 81.3 | 423.0 | 83.4 | 200 | Φ42 | Φ89×2 | Φ76 | Φ42 | 3000×1700×1800 | |
| 40 | 182.1 | 79.8 | 224.7 | 83.1 | 275.1 | 86.1 | 332.7 | 88.8 | 399.6 | 91.2 | |||||||||
| 45 | 167.7 | 87.3 | 207.9 | 90.9 | 2556 | 94.2 | 310.2 | 97.5 | 374.7 | 100.2 | |||||||||
| LXPL-BHF4 -160M | 4 | 35 | 260.4 | 97.6 | 320.8 | 101.5 | 309.4 | 105.2 | 471.2 | 108.4 | 564.0 | 111.2 | 250 | Φ57 | Φ108 ×2 | Φ108 | Φ76 | 3800×1700×1800 | |
| 40 | 242.8 | 106.4 | 299.6 | 110.8 | 366.8 | 114.8 | 443.6 | 118.4 | 532.8 | 121.6 | |||||||||
| 45 | 223.6 | 116.4 | 277.2 | 121.2 | 340.8 | 125.6 | 413.6 | 130.0 | 499.6 | 133.6 | |||||||||
| LXPL-HF -50 milijuna | RC2-180B -Z (50KS) | 1 | 35 | 85.9 | 30.3 | 105.3 | 31.5 | 128.1 | 32.6 | 154.6 | 33.6 | 185.1 | 34.5 | 100 | Φ35 | Φ67 | Φ42 | Φ35 | 2300×900×1100 |
| 40 | 79.8 | 33.1 | 98.4 | 34.4 | 120.4 | 35.7 | 145.6 | 36.8 | 174.8 | 37.8 | |||||||||
| 45 | 73.6 | 36.1 | 91.1 | 37.6 | 112.3 | 39.0 | 136.2 | 40.3 | 163.9 | 41.5 | |||||||||
| LXPL-BHF2 -100 milijuna | RC2-180B -ZP (50KS) | 2 | 35 | 171.8 | 60.6 | 210.6 | 63.0 | 2562 | 652 | 309.2 | 67.2 | 370.2 | 69.0 | 200 | Φ42 | Φ108 | Φ76 | Φ42 | 2300×1700×1800 |
| 40 | 159.6 | 66.2 | 195.8 | 88.8 | 240.8 | 74.1 | 291.2 | 73.6 | 349.6 | 75.6 | |||||||||
| 45 | 147.2 | 72.2 | 182.2 | 75.2 | 224.6 | 78.0 | 272.4 | 80.6 | 327.8 | 83.0 | |||||||||
| LXPL-BHF3 -150 milijuna | 3 | 35 | 257.7 | 90.9 | 315.9 | 94.5 | 384.3 | 97.8 | 463.8 | 100.8 | 555.3 | 103.5 | 250 | Φ54 | Φ89×2 | Φ76 | Φ54 | 3500×1700×1800 | |
| 40 | 239.4 | 99.3 | 295.2 | 103.2 | 361.2 | 107.1 | 436.8 | 110.4 | 524.4 | 113.4 | |||||||||
| 45 | 220.8 | 108.3 | 273.3 | 112.8 | 336.9 | 117.0 | 408.6 | 120.9 | 491.7 | 124.5 | |||||||||
| LXPL-BHF4 -200 milijuna | 4 | 35 | 343.5 | 121.2 | 421.2 | 126.0 | 512.4 | 130.4 | 618.4 | 134.4 | 740.4 | 138.0 | 300 | Φ57 | Φ108 ×2 | Φ108 | Φ76 | 4400×1700×1800 | |
| 40 | 319.2 | 132.4 | 393.8 | 137.6 | 481.6 | 142.8 | 582.4 | 147.2 | 699.2 | 151.2 | |||||||||
| 45 | 294.4 | 144.4 | 364.4 | 150.4 | 449.2 | 156.0 | 544.8 | 161.2 | 655.6 | 166.0 | |||||||||
| Model jedinice | Kom.Model | Com. Curtity | Kondenzirajući temp. (℃) | Temp. isparavanja (℃) | Rezervoar (L) | Opskrba cijev (mm) | Usisavanje cijev (mm) | Gas Outiet cijev (mm) | tekućina ulazna cijev (mm) | Dimenzija (mm) (D׊×V) | |||||||||
| -15 | -10 | -5 | 0 | 5 | |||||||||||||||
| Kapacitet hlađenja/ulazna snaga (kw) | |||||||||||||||||||
| LXPL-BHF-55M | RC2-200B -Z (55KS) | 1 | 35 | 91.9 | 33.6 | 113.1 | 34.9 | 137.6 | 36.1 | 166.1 | 37.3 | 198.9 | 38.2 | 100 | Φ42 | Φ76 | Φ42 | Φ54 | 2300×900×1100 |
| 40 | 85.7 | 36.6 | 105.7 | 38.1 | 129.4 | 39.5 | 156.5 | 40.8 | 187.8 | 41.9 | |||||||||
| 45 | 78.9 | 40.0 | 97.8 | 41.6 | 120.2 | 43.2 | 146.3 | 44.7 | 176.1 | 46.0 | |||||||||
| LXPL-BHF2 -110M | RC2-200B -ZP (55KS) | 2 | 35 | 183.8 | 67.2 | 226.2 | 69.8 | 275.2 | 72.2 | 332.2 | 74.6 | 397.8 | 76.4 | 200 | Φ57 | Φ108 | Φ76 | Φ76 | 2330×1700×1100 |
| 40 | 171.4 | 73.2 | 211.4 | 73.2 | 258.8 | 79.0 | 313.0 | 81.6 | 375.6 | 83.3 | |||||||||
| 45 | 157.8 | 80.0 | 195.6 | 83.2 | 240.4 | 86.4 | 292.6 | 89.4 | 352.2 | 92.0 | |||||||||
| LXPL-BHF3 -165M | 3 | 35 | 275.7 | 100.8 | 399.3 | 104.7 | 412.8 | 108.3 | 498.3 | 111.9 | 596.7 | 114.6 | 250 | Φ57 | Φ89×2 | Φ89 | Φ76 | 2300×1700×1800 | |
| 40 | 257.1 | 109.8 | 317.1 | 114.3 | 388.2 | 188.5 | 469.5 | 122.4 | 563.4 | 125.7 | |||||||||
| 45 | 236.7 | 120.2 | 293.4 | 124.8 | 360.6 | 129.6 | 438.9 | 134.1 | 528.3 | 138.0 | |||||||||
| LXPL-BHF4 -220M | M | 35 | 367.6 | 134.4 | 452.4 | 139.6 | 550.4 | 144.4 | 664.4 | 149.2 | 795.6 | 152.8 | 300 | Φ57 | Φ108 ×2 | Φ108 | Φ76 | 4400×1700×1800 | |
| 40 | 342.8 | 146.4 | 422.8 | 152.4 | 517.6 | 158.0 | 626.0 | 163.2 | 751.2 | 167.6 | |||||||||
| 45 | 315.6 | 160.0 | 391.2 | 166.4 | 480.8 | 172.8 | 585.2 | 177.8 | 704.4 | 184.0 | |||||||||
| LXPL-HF -60M | RC2-230B -Z (60KS) | 1 | 35 | 114.1 | 33.6 | 140.5 | 44.2 | 170.9 | 45.8 | 206.3 | 47.3 | 247.1 | 48.4 | 150 | Φ35 | Φ76 | Φ54 | Φ35 | 2300×900×1250 |
| 40 | 106.3 | 46.4 | 131.2 | 48.3 | 160.7 | 50.0 | 194.4 | 51.7 | 233.3 | 53.1 | |||||||||
| 45 | 97.9 | 50.7 | 121.4 | 52.8 | 149.3 | 54.7 | 181.7 | 56.6 | 218.8 | 58.2 | |||||||||
| LXPL-BHF2 -120 milijuna | RC2-230B -ZP (60KS) | 2 | 35 | 228.2 | 85.0 | 281.0 | 88.4 | 341.8 | 91.6 | 412.6 | 94.4 | 494.2 | 96.8 | 200 | Φ42 | Φ133 | Φ76 | Φ42 | 2600×1700×1900 |
| 40 | 212.6 | 92.8 | 262.4 | 96.6 | 321.4 | 100.0 | 388.8 | 103.4 | 466.6 | 106.2 | |||||||||
| 45 | 195.8 | 101.4 | 242.8 | 105.6 | 298.6 | 109.4 | 363.4 | 113.2 | 437.6 | 116.4 | |||||||||
| LXPL-BHF3 -180M | 3 | 35 | 342.3 | 127.5 | 421.5 | 132.6 | 512.7 | 134.7 | 618.9 | 141.6 | 741.3 | 145.2 | 300 | Φ54 | Φ108 ×2 | Φ76 | Φ67 | 3500×1700×1900 | |
| 40 | 318.9 | 139.2 | 393.6 | 144.9 | 482.1 | 150.0 | 583.2 | 155.1 | 699.9 | 159.3 | |||||||||
| 45 | 293.7 | 152.1 | 364.2 | 158.4 | 447.9 | 164.1 | 545.1 | 169.8 | 656.4 | 174.6 | |||||||||
| LXPL-BHF4 -240M | 4 | 35 | 456.4 | 170.0 | 562.0 | 176.8 | 683.6 | 183.2 | 825.2 | 188.8 | 988.4 | 193.6 | 400 | Φ57 | Φ133 ×2 | Φ108 | Φ89 | 4400×1700×1900 | |
| 40 | 425.2 | 185.6 | 524.8 | 193.2 | 642.8 | 200.0 | 777.6 | 206.8 | 933.2 | 212.4 | |||||||||
| 45 | 391.6 | 202.8 | 485.6 | 211.2 | 597.2 | 218.8 | 726.8 | 266.4 | 875.2 | 232.8 | |||||||||
| LXPL-HF -70M | RC2-260B -Z (70KS) | 1 | 35 | 123.4 | 43.8 | 151.3 | 45.6 | 184.1 | 47.2 | 222.2 | 448.7 | 266.1 | 49.9 | 150 | Φ35 | Φ76 | Φ54 | Φ35 | 2300×900×1250 |
| 40 | 114.7 | 47.9 | 141.5 | 49.8 | 173.1 | 51.6 | 209.3 | 53.3 | 251.3 | 54.7 | |||||||||
| 45 | 105.7 | 52.3 | 130.9 | 54.4 | 161.4 | 56.4 | 195.7 | 58.3 | 235.6 | 60.0 | |||||||||
| LXPL-BHF2 -140M | RC2-260B -ZP (70KS) | 2 | 35 | 246.8 | 87.6 | 302.6 | 91.2 | 368.2 | 94.4 | 444.4 | 97.4 | 532.2 | 99.8 | 200 | Φ54 | Φ133 | Φ76 | Φ54 | 2600×1700×1900 |
| 40 | 229.4 | 95.8 | 283.0 | 99.6 | 346.2 | 103.2 | 418.6 | 106.6 | 502.6 | 109.4 | |||||||||
| 45 | 211.4 | 104.6 | 261.8 | 108.8 | 322.8 | 112.8 | 391.4 | 116.6 | 471.2 | 120.0 | |||||||||
| LXPL-BHF3 -210M | 3 | 35 | 370.2 | 131.4 | 453.9 | 136.8 | 552.3 | 141.6 | 666.6 | 146.1 | 798.3 | 149.7 | 300 | Φ54 | Φ108 ×2 | Φ108 | Φ67 | 3500×1700×1900 | |
| 40 | 344.1 | 143.7 | 424.5 | 149.4 | 591.3 | 154.8 | 627.9 | 159.9 | 753.9 | 164.1 | |||||||||
| 45 | 317.1 | 156.9 | 392.7 | 163.2 | 484.2 | 169.2 | 587.1 | 174.9 | 706.8 | 180.0 | |||||||||
| LXPL-BHF4 -280M | 4 | 35 | 493.6 | 175.2 | 605.2 | 182.4 | 736.4 | 188.8 | 888.8 | 194.8 | 1064.4 | 199.6 | 400 | Φ57 | Φ133 ×2 | Φ108 | Φ89 | 4400×1700×1900 | |
| 40 | 458.8 | 191.6 | 566.0 | 199.2 | 692.4 | 206.4 | 837.2 | 213.2 | 1005.2 | 218.8 | |||||||||
| 45 | 422.8 | 209.2 | 523.6 | 217.6 | 645.6 | 225.6 | 782.8 | 233.2 | 942.4 | 240.0 | |||||||||
| Model jedinice | Cam.Model | Com, Cuartity | Kondenzirajući temp. (℃) | Temp. isparavanja (℃) | Rezervoar (L) | Opskrba cijev (mm) | Usisavanje cijev (mm) | Gas Outiet cijev (mm) | tekućina ulazna cijev (mm) | Dimenzija (mm) (D׊×V) | ||||||||||
| -15 | -10 | -5 | 0 | 5 | ||||||||||||||||
| Kapacitet hlađenja/ulazna snaga (kw) | ||||||||||||||||||||
| LXPL-BHF-75M | RC2-300B -Z (75KS) | 1 | 35 | 145.4 | 50.5 | 178.3 | 52.5 | 216.9 | 54.4 | 261.8 | 56.1 | 313.6 | 57.5 | 200 | Φ57 | Φ89 | Φ67 | Φ67 | 2300×900×1250 | |
| 40 | 135.3 | 55.2 | 167.3 | 57.4 | 203.9 | 59.5 | 246.6 | 61.4 | 296.1 | 63.1 | ||||||||||
| 45 | 127.4 | 60.3 | 154.4 | 62.7 | 190.1 | 65.1 | 230.6 | 67.3 | 277.6 | 69.2 | ||||||||||
| LXPL-BHF2 -150 milijuna | RC2-300B -ZP (75KS) | 2 | 35 | 290.8 | 101.0 | 356.6 | 105.0 | 433.8 | 108.8 | 523.6 | 112.2 | 627.2 | 115.0 | 250 | Φ57 | Φ133 | Φ89 | Φ76 | 2600×1700×1900 | |
| 40 | 270.6 | 101.0 | 334.6 | 114.8 | 407.8 | 119.0 | 493.2 | 122.8 | 5922 | 126.2 | ||||||||||
| 45 | 249.4 | 120.6 | 308.8 | 125.4 | 380.2 | 130.2 | 461.2 | 134.6 | 555.2 | 138.4 | ||||||||||
| LXPL-BHF3 -225M | 3 | 35 | 436.2 | 151.5 | 534.9 | 157.5 | 650.7 | 163.2 | 785.4 | 168.3 | 940.8 | 172.5 | 400 | Φ57 | Φ108 ×2 | Φ108 | Φ89 | 3500×1700×1900 | ||
| 40 | 405.9 | 165.6 | 501.9 | 172.2 | 611.7 | 178.5 | 739.8 | 184.2 | 888.3 | 189.3 | ||||||||||
| 45 | 374.1 | 180.9 | 463.2 | 188.1 | 570.3 | 195.3 | 691.8 | 201.9 | 832.8 | 207.6 | ||||||||||
| LXPL-BHF4 -300 milijuna | 4 | 35 | 581.6 | 202.0 | 731.2 | 210.0 | 867.6 | 217.6 | 1047.2 | 224.4 | 1254.4 | 230.0 | 500 | Φ57 | Φ133 ×2 | Φ108 | Φ89 | 4400×1700×1900 | ||
| 40 | 541.2 | 220.8 | 699.2 | 229.6 | 815.6 | 238.0 | 986.4 | 245.6 | 1184.4 | 252.4 | ||||||||||
| 45 | 498.8 | 241.2 | 617.6 | 250.8 | 760.4 | 260.4 | 922.4 | 269.2 | 1110.4 | 276.8 | ||||||||||
| LXPL-HF -80M | RC2-310B -Z (80KS) | 1 | 35 | 153.7 | 53.8 | 188.4 | 55.9 | 229.2 | 57.9 | 276.6 | 59.7 | 331.6 | 61.2 | 200 | Φ35 | Φ76 | Φ54 | Φ35 | 2600×900×1400 | |
| 40 | 142.9 | 58.7 | 176.8 | 61.1 | 215.5 | 63.3 | 260.6 | 65.3 | 312.8 | 67.1 | ||||||||||
| 45 | 131.7 | 64.1 | 163.1 | 66.7 | 200.9 | 69.2 | 243.7 | 71.6 | 293.3 | 73.6 | ||||||||||
| LXPL-BHF2 -160M | RC2-310B -ZP (80KS) | 2 | 35 | 307.4 | 107.8 | 376.8 | 111.8 | 458.4 | 115.8 | 553.2 | 119.4 | 662.6 | 122.4 | 250 | Φ57 | Φ133 | Φ76 | Φ54 | 3000×1800×2100 | |
| 40 | 285.8 | 117.4 | 353.6 | 122.2 | 431.0 | 126.6 | 521.2 | 130.6 | 625.6 | 134.2 | ||||||||||
| 45 | 263.4 | 128.2 | 326.2 | 133.4 | 401.8 | 138.4 | 487.4 | 143.2 | 586.6 | 147.2 | ||||||||||
| LXPL-BHF3 -240M | 3 | 35 | 461.1 | 161.4 | 565.2 | 167.7 | 687.6 | 173.7 | 829.8 | 179.1 | 993.9 | 183.6 | 400 | Φ54 | Φ108 ×2 | Φ108 | Φ67 | 3500×1700×1900 | ||
| 40 | 428.7 | 176.1 | 530.4 | 183.3 | 646.5 | 189.9 | 781.8 | 195.9 | 938.4 | 201.3 | ||||||||||
| 45 | 395.1 | 192.3 | 489.3 | 200.1 | 602.7 | 207.6 | 731.1 | 214.8 | 879.9 | 220.8 | ||||||||||
| LXPL-BHF4 -320M | 4 | 35 | 614.8 | 215.2 | 753.6 | 223.6 | 916.8 | 231.6 | 1106.4 | 238.8 | 1325.2 | 244.8 | 500 | Φ57 | Φ133 ×2 | Φ108 | Φ89 | 4000×1700×1900 | ||
| 40 | 571.6 | 234.8 | 707.2 | 244.4 | 862.0 | 253.2 | 1042.4 | 261.2 | 1251.2 | 268.4 | ||||||||||
| 45 | 526.8 | 256.4 | 376.8 | 266.8 | 803.6 | 276.8 | 974.8 | 286.4 | 1173.2 | 299.4 | ||||||||||
| LXPL-HF -90M | RC2-340B -Z (90KS) | 1 | 35 | 171.1 | 58.0 | 209.8 | 60.3 | 255.2 | 62.5 | 308.0 | 64.4 | 368.9 | 66.1 | 200 | Φ42 | Φ108 | Φ67 | Φ54 | 2600×850×1400 | |
| 40 | 159.3 | 63.4 | 196.8 | 65.9 | 239.9 | 68.3 | 290.1 | 70.5 | 348.3 | 72.4 | ||||||||||
| 45 | 146.9 | 69.2 | 181.8 | 72.0 | 223.7 | 74.7 | 271.3 | 77.2 | 326.6 | 79.5 | ||||||||||
| LXPL-BHF2 -180M | RC2-340B -ZP (90KS) | 2 | 35 | 342.2 | 116.0 | 419.6 | 120.6 | 510.4 | 125.0 | 616.0 | 128.8 | 737.8 | 132.2 | 300 | Φ54 | Φ133 | Φ76 | Φ54 | 3000×1800×2100 | |
| 40 | 318.9 | 126.8 | 393.6 | 131.8 | 479.8 | 136.6 | 580.2 | 141.0 | 696.6 | 144.8 | ||||||||||
| 45 | 293.8 | 138.4 | 363.8 | 144.0 | 447.4 | 149.4 | 542.6 | 154.4 | 653.2 | 159.0 | ||||||||||
| LXPL-BHF3 -270M | 3 | 35 | 513.3 | 174.0 | 629.4 | 180.9 | 765.6 | 187.5 | 924.0 | 193.2 | 1106.7 | 198.3 | 400 | Φ57 | Φ133 ×2 | Φ108 | Φ89 | 3800×1800×2100 | ||
| 40 | 477.9 | 190.2 | 590.4 | 197.7 | 719.7 | 204.9 | 870.3 | 211.5 | 1044.9 | 217.2 | ||||||||||
| 45 | 440.7 | 207.6 | 545.4 | 216.0 | 671.1 | 224.1 | 813.9 | 231.6 | 979.8 | 238.5 | ||||||||||
| LXPL-BHF4 -360M | 4 | 35 | 684.4 | 232.0 | 839.2 | 241.2 | 1020.8 | 250.0 | 1232.0 | 2576 | 1475.6 | 264.4 | 600 | Φ57 | Φ159 ×2 | Φ133 | Φ89 | 4600×1800×2100 | ||
| 40 | 637.2 | 253.6 | 787.2 | 263.6 | 959.6 | 273.2 | 1160.4 | 282.0 | 1393.2 | 289.6 | ||||||||||
| 45 | 587.6 | 276.8 | 727.2 | 288.0 | 894.8 | 298.8 | 1085.2 | 308.8 | 1306.4 | 318.0 | ||||||||||
| Model jedinice | Kom.Model | Com, Curtity | Kondenzirajući temp. (℃) | Temp. isparavanja (℃) | Rezervoar (L) | Opskrba cijev (mm) | Usisavanje cijev (mm) | Gas Outiet cijev (mm) | tekućina ulazna cijev (mm) | Dimenzija (mm) (DxŠ×V) | ||||||||||
| -15 | -10 | -5 | 0 | 5 | ||||||||||||||||
| Rashladni kapacitet/ulazna snaga (kw) | ||||||||||||||||||||
| LXPL-BHF -100 milijuna | RC2-370B -Z (100KS) | 1 | 35 | 184.3 | 62.7 | 226.0 | 65.2 | 274.8 | 67.5 | 331.7 | 69.6 | 397.3 | 71.3 | 100 | Φ42 | Φ108 | Φ67 | Φ57 | 2600×850×1400 | |
| 40 | 171.5 | 68.4 | 212.0 | 71.5 | 285.4 | 73.8 | 312.5 | 76.2 | 375.1 | 78.3 | ||||||||||
| 45 | 158.1 | 74.8 | 195.8 | 77.8 | 240.9 | 80.7 | 292.2 | 83.4 | 351.7 | 85.8 | ||||||||||
| LXPL-BHF2 -200 milijuna | RC2-370B -ZP (100KS) | 2 | 35 | 368.6 | 125.4 | 452.0 | 130.4 | 549.6 | 135.0 | 663.4 | 139.2 | 794.6 | 142.8 | 300 | Φ54 | Φ159 | Φ108 | Φ67 | 3500×1900×2100 | |
| 40 | 343.0 | 136.8 | 424.0 | 142.4 | 516.8 | 147.6 | 625.0 | 152.4 | 750.2 | 156.4 | ||||||||||
| 45 | 316.2 | 149.6 | 391.6 | 155.6 | 481.8 | 161.4 | 584.4 | 166.8 | 703.4 | 171.8 | ||||||||||
| LXPL-BHF3 -300 milijuna | 3 | 35 | 552.9 | 188.1 | 678.0 | 195.6 | 824.4 | 202.5 | 995.1 | 208.8 | 1191.9 | 214.2 | 500 | Φ57 | Φ133 ×2 | Φ108 | Φ89 | 4400×1900×2100 | ||
| 40 | 514.5 | 205.2 | 636.0 | 213.6 | 775.2 | 221.4 | 937.5 | 228.6 | 1125.3 | 234.6 | ||||||||||
| 45 | 474.3 | 224.4 | 587.4 | 233.4 | 722.7 | 242.1 | 876.6 | 205.2 | 1055.1 | 257.7 | ||||||||||
| LXPL-BHF4 -400 milijuna | 4 | 35 | 737.2 | 250.8 | 904.0 | 260.8 | 1099.2 | 270.0 | 1326.8 | 278.4 | 1589.2 | 285.6 | 600 | Φ57 | Φ159 ×2 | Φ133 | Φ89 | 5300×1900×2100 | ||
| 40 | 686.0 | 273.6 | 848.0 | 284.8 | 1033.6 | 295.2 | 1250.0 | 304.8 | 1500.4 | 312.8 | ||||||||||
| 45 | 632.4 | 299.2 | 783.2 | 313.2 | 963.6 | 322.8 | 1168.8 | 333.6 | 1406.8 | 343.6 | ||||||||||
| LXPL-HF -110M | RC2-410B -Z (110KS) | 1 | 35 | 200.4 | 69.3 | 245.9 | 72.1 | 298.8 | 67.5 | 360.6 | 77.0 | 432.0 | 78.9 | 250 | Φ42 | Φ108 | Φ67 | Φ54 | 2750×850×1450 | |
| 40 | 186.4 | 75.7 | 230.5 | 78.7 | 280.9 | 81.6 | 339.8 | 84.3 | 407.9 | 86.5 | ||||||||||
| 45 | 171.8 | 82.7 | 212.8 | 86.0 | 261.9 | 89.3 | 317.7 | 92.3 | 352.8 | 95.0 | ||||||||||
| LXPL-BHF2 -220M | RC2-410B -ZP (110KS) | 2 | 35 | 400.8 | 138.6 | 491.4 | 144.2 | 597.6 | 135.0 | 721.2 | 154.0 | 864.0 | 157.8 | 300 | Φ57 | Φ159 | Φ108 | Φ76 | 3500×1900×2150 | |
| 40 | 372.8 | 151.4 | 461.0 | 157.4 | 561.8 | 163.2 | 679.6 | 168.6 | 815.8 | 137.0 | ||||||||||
| 45 | 343.6 | 165.4 | 425.6 | 172.0 | 523.8 | 178.6 | 635.4 | 184.6 | 764.8 | 190.0 | ||||||||||
| LXPL-BHF3 -330M | 3 | 35 | 601.2 | 207.9 | 737.1 | 216.3 | 896.4 | 202.5 | 1081.8 | 231.0 | 1296.0 | 236.7 | 500 | Φ57 | Φ133 ×2 | Φ108 | Φ89 | 4400×1000×2150 | ||
| 40 | 559.2 | 227.1 | 691.5 | 236.1 | 842.7 | 244.8 | 1019.4 | 252.9 | 1223.7 | 259.5 | ||||||||||
| 45 | 515.4 | 248.1 | 638.4 | 258.0 | 785.7 | 267.9 | 953.1 | 276.9 | 1147.2 | 285.0 | ||||||||||
| LXPL-BHF4 -440M | 4 | 35 | 801.6 | 277.2 | 982.8 | 288.4 | 1195.2 | 270.0 | 1442.4 | 308.0 | 1728.0 | 315.6 | 600 | Φ57 | Φ159 ×2 | Φ133 | Φ89 | 5300×1900×2150 | ||
| 40 | 745.6 | 302.8 | 922.0 | 314.8 | 1123.6 | 326.4 | 1359.2 | 337.2 | 1631.6 | 346.0 | ||||||||||
| 45 | 687.2 | 330.8 | 851.2 | 344.0 | 1047.6 | 357.2 | 1270.8 | 369.2 | 1529.6 | 380.0 | ||||||||||
| LXPL-HF -125M | RC2-470B -Z (125KS) | 1 | 35 | 238.6 | 80.1 | 292.5 | 83.3 | 355.8 | 86.3 | 429.4 | 88.9 | 514.3 | 91.2 | 250 | Φ42 | Φ108 | Φ67 | Φ54 | 2750×870×1450 | |
| 40 | 222.2 | 87.5 | 274.4 | 91.0 | 334.5 | 94.3 | 404.5 | 97.3 | 485.6 | 100.0 | ||||||||||
| 45 | 204.8 | 95.5 | 253.6 | 994 | 311.9 | 103.1 | 378.3 | 106.6 | 455.3 | 109.7 | ||||||||||
| LXPL-BHF2 -250 milijuna | RC2-470B -ZP (125KS) | 2 | 35 | 477.2 | 160.2 | 585.0 | 166.6 | 711.6 | 172.6 | 858.8 | 177.8 | 1028.6 | 182.4 | 400 | Φ57 | Φ159 | Φ108 | Φ67 | 3500×1900×2550 | |
| 40 | 444.4 | 1750 | 548.8 | 182.0 | 699.0 | 188.6 | 809.0 | 194.5 | 971.2 | 200.0 | ||||||||||
| 45 | 409.8 | 191.0 | 507.2 | 198.8 | 623.8 | 206.2 | 756.6 | 213.2 | 910.6 | 219.4 | ||||||||||
| LXPL-BHF3 -375M | 3 | 35 | 715.8 | 240.3 | 877.5 | 249.9 | 1067.4 | 258.9 | 1288.2 | 266.7 | 1542.9 | 273.6 | 600 | Φ57 | Φ133 ×2 | Φ133 | Φ89 | 4500×1900×2500 | ||
| 40 | 666.6 | 262.5 | 838.2 | 273.0 | 1003.5 | 282.9 | 1213.5 | 291.9 | 1456.8 | 300.0 | ||||||||||
| 45 | 614.4 | 286.5 | 760.8 | 298.2 | 935.7 | 309.3 | 1134.9 | 319.8 | 1365.9 | 329.1 | ||||||||||
| LXPL-BHF4 -500 milijuna | 4 | 35 | 954.4 | 320.4 | 1170.0 | 333.2 | 1423.2 | 3452 | 1717.6 | 355.6 | 2057.2 | 364.8 | 800 | Φ76 | Φ159 ×2 | Φ159 | Φ108 | 5400×1900×2500 | ||
| 40 | 888.8 | 350.01 | 1097.6 | 364.0 | 1338.0 | 377.2 | 1618.0 | 389.2 | 1942.4 | 438.8 | ||||||||||
| 45 | 819.2 | 382.0 | 1014.4 | 397.6 | 1247.6 | 412.4 | 1513.2 | 426.4 | 1821.2 | 438.8 | ||||||||||
| Model jedinice | Kom.Model | Cam. Cuartity | Kondenzirajući temp. (℃) | Temp. isparavanja (℃) | Rezervoar (L) | Opskrba cijev (mm) | Usisavanje cijev (mm) | Gas Outiet cijev (mm) | tekućina ulazna cijev (mm) | Dimenzija (mm) (D׊×V) | |||||||||
| -15 | -10 | -5 | 0 | 5 | |||||||||||||||
| Kapacitet hlađenja Ulazna snaga (kw) | |||||||||||||||||||
| LXPL-BHF -130M | RC2-510B -Z (130KS) | 1 | 35 | 254.3 | 85.9 | 311.9 | 89.3 | 379.3 | 92.5 | 457.8 | 95.4 | 548.3 | 97.8 | 200 | Φ42 | Φ108 | Φ67 | Φ54 | 3050×870×1450 |
| 40 | 236.8 | 93.8 | 292.6 | 97.5 | 356.6 | 101.1 | 431.3 | 104.4 | 517.7 | 107.2 | |||||||||
| 45 | 218.3 | 102.4 | 270.3 | 106.6 | 332.5 | 110.6 | 403.3 | 114.3 | 485.5 | 117.6 | |||||||||
| LXPL-BHF2 -260M | RC2-510B -ZP (130KS) | 2 | 35 | 508.6 | 171.8 | 623.8 | 178.6 | 758.6 | 185.0 | 915.6 | 190.8 | 1096.6 | 195.6 | 400 | Φ57 | Φ159 | Φ133 | Φ89 | 3250×2100×1750 |
| 40 | 473.6 | 187.6 | 585.2 | 195.0 | 713.2 | 202.2 | 862.6 | 208.8 | 1035.4 | 214.4 | |||||||||
| 45 | 436.6 | 204.8 | 540.6 | 213.2 | 665.0 | 221.2 | 806.6 | 228.6 | 971.0 | 235.2 | |||||||||
| LXPL-BHF3 -390M | 3 | 35 | 762.9 | 257.7 | 935.7 | 267.9 | 1137.9 | 277.5 | 1373.4 | 286.2 | 1644.9 | 293.4 | 600 | Φ76 | Φ133 ×2 | Φ159 | Φ89 | 4350×2100×1800 | |
| 40 | 710.4 | 281.4 | 877.8 | 292.5 | 1069.8 | 303.3 | 1293.9 | 313.2 | 1553.1 | 321.6 | |||||||||
| 45 | 654.9 | 307.2 | 810.9 | 319.8 | 997.5 | 331.8 | 1209.9 | 342.9 | 1456.5 | 352.8 | |||||||||
| LXPL-BHF4 -520M | 4 | 35 | 1017.2 | 343.6 | 1247.6 | 357.2 | 1517.2 | 370.0 | 1831.2 | 381.6 | 2193.2 | 391.2 | 800 (Izvana) | Φ76 | Φ159 ×2 | Φ159 | Φ108 | 5400×2100×2050 | |
| 40 | 947.2 | 375.2 | 1170.4 | 390.0 | 1426.4 | 404.4 | 1725.2 | 417.66 | 2070.8 | 428.8 | |||||||||
| 45 | 873.2 | 409.6 | 1081.2 | 426.4 | 1330.0 | 442.4 | 1613.2 | 457.2 | 1942.0 | 470.4 | |||||||||
| LXPL-HF -140M | RC2-550B -Z (140KS) | 1 | 35 | 271.3 | 94.4 | 322.6 | 98.2 | 404.6 | 101.7 | 488.3 | 104.9 | 584.8 | 107.5 | 200 | Φ42 | Φ108 | Φ67 | Φ54 | 3050×870×1450 |
| 40 | 252.3 | 103.1 | 312.1 | 107.3 | 380.3 | 111.2 | 460.0 | 114.8 | 552.2 | 117.9 | |||||||||
| 45 | 232.5 | 112.7 | 288.0 | 117.2 | 354.6 | 121.6 | 430.1 | 125.7 | 517.8 | 129.4 | |||||||||
| LXPL-BHF2 -280M | RC2-550B -ZP (140KS) | 2 | 35 | 542.6 | 188.8 | 665.2 | 196.4 | 809.2 | 203.4 | 976.6 | 209.8 | 1169.6 | 215.0 | 400 | Φ57 | Φ159 | Φ133 | Φ89 | 3400×2150×1750 |
| 40 | 504.6 | 206.2 | 624.2 | 214.6 | 760.6 | 222.4 | 920.0 | 229.6 | 1104.4 | 235.8 | |||||||||
| 45 | 465.0 | 225.4 | 576.0 | 234.4 | 709.2 | 243.2 | 860.2 | 251.4 | 1035.6 | 258.8 | |||||||||
| LXPL-BHF3 -420M | 3 | 35 | 813.9 | 2832 | 997.8 | 294.6 | 1213.8 | 305.1 | 1464.9 | 314.7 | 1754.4 | 322.5 | 600 | Φ76 | Φ133 ×2 | Φ159 | Φ89 | 4550×2150×2050 | |
| 40 | 765.9 | 309.3 | 936.3 | 321.9 | 1140.9 | 333.6 | 1380.0 | 344.4 | 1656.6 | 353.7 | |||||||||
| 45 | 697.5 | 338.1 | 864.0 | 351.6 | 1063.8 | 364.8 | 1290.3 | 377.1 | 1553.4 | 388.2 | |||||||||
| LXPL-BHF4 -560M | 4 | 35 | 1085.2 | 377.6 | 1330.4 | 392.8 | 1618.4 | 406.8 | 1953.2 | 419.6 | 2339.2 | 430.0 | 800 (Izvana) | Φ76 | Φ159 ×2 | Φ159 | Φ108 | 5600×2150×2050 | |
| 40 | 1009.2 | 412.4 | 1248.4 | 4292 | 1521.2 | 444.8 | 1840.0 | 459.2 | 2208.8 | 471.6 | |||||||||
| 45 | 930.0 | 450.8 | 1152.0 | 466.8 | 1418.4 | 486.4 | 1720.4 | 502.8 | 2071.2 | 517.6 | |||||||||
| LXPL-HF -150 milijuna | RC2-580B -Z (150KS | 1 | 35 | 299.9 | 101.6 | 367.7 | 105.7 | 447.2 | 109.5 | 539.8 | 112.9 | 646.5 | 115.8 | 200 | Φ42 | Φ108 | Φ67 | Φ54 | 3050×870×1450 |
| 40 | 279.2 | 111.0 | 345.0 | 115.5 | 420.4 | 119.7 | 508.5 | 123.6 | 610.4 | 126.9 | |||||||||
| 45 | 257.4 | 121.3 | 318.6 | 126.2 | 392.0 | 130.9 | 475.5 | 135.3 | 572.4 | 139.3 | |||||||||
| LXPL-BHF2 -300 milijuna | RC2-580B -ZP (150KS) | 2 | 35 | 599.8 | 203.2 | 735.4 | 211.4 | 894.4 | 219.0 | 1079.6 | 225.8 | 1293.0 | 231.6 | 500 | Φ57 | Φ159 | Φ133 | Φ89 | 3500×2150×1750 |
| 40 | 558.4 | 222.0 | 690.0 | 231.0 | 840.8 | 239.4 | 1017.0 | 247.2 | 1220.8 | 253.8 | |||||||||
| 45 | 514.8 | 242.6 | 637.2 | 252.4 | 784.0 | 261.8 | 951.0 | 270.5 | 1144.8 | 278.5 | |||||||||
| LXPL-BHF3 -450M | 3 | 35 | 899.7 | 304.8 | 1103.1 | 317.1 | 1341.6 | 328.5 | 1619.4 | 338.7 | 1939.5 | 347.4 | 800 (Izvana) | Φ76 | Φ133 ×2 | Φ133 | Φ108 | 4650×2150×2050 | |
| 40 | 837.6 | 333.0 | 1035.0 | 346.51 | 1261.2 | 359.1 | 1525.5 | 370.8 | 1831.2 | 380.7 | |||||||||
| 45 | 772.2 | 363.9 | 955.8 | 378.6 | 1176.0 | 392.7 | 1426.5 | 405.9 | 1717.2 | 417.9 | |||||||||
| LXPL-BHF4 -600M | 4 | 35 | 1199.6 | 406.4 | 1470.8 | 422.8 | 1788.8 | 438.0 | 2159.2 | 451.6 | 2586.0 | 463.2 | 800 (Izvana) | Φ76 | Φ159 ×2 | Φ159 | Φ108 | 5800×2150×2350 | |
| 40 | 1116.8 | 444.0 | 1380.0 | 462.0 | 1681.6 | 478.8 | 2034.0 | 494.4 | 2441.6 | 507.6 | |||||||||
| 45 | 1029.6 | 485.2 | 1274.4 | 504.8 | 1568.0 | 5236 | 1902.0 | 541.2 | 2289.6 | 557.2 | |||||||||
Prikaz detalja
Kontaktirajte nas
O NAMA
Zhejiang Lanxi Refrigeration Equipment Co., Ltd.
Kao Kina Hanbell jedinica za srednje do visoke temperature Dobavljači i Hanbell jedinica za srednje do visoke temperature Tvornica,
Zhejiang Lanxi Refrigeration Equipment Co., Ltd. specijalizirana za učinkovita, zelena i održiva rashladna rješenja. Koristeći visokokvalitetne proizvode i inovativne tehnologije, služimo sektorima prehrane, farmacije, kemije i logistike hladnog lanca, stvarajući energetski učinkovite i ekološki prihvatljive sustave za naše kupce te potičući obostrano koristan razvoj industrije i okoliša.
Potvrda o časti
Vijesti
-
Što je industrijski hladnjak zraka i kako radi u rashladnom sustavu? Zamislite rashladnu komoru srednje veličine izgrađenu za držanje zamrznute hrane na -22°C. Kompresorska jedinica i kondenzator nalaze se vani, ali oprema koja ...
PROČITAJ VIŠE -
Kompletan vodič za odabir kondenzatora: Odaberite pravi kondenzator za industrijske i HVAC sustave Kondenzator je ključna komponenta za prijenos topline koja se široko koristi u HVAC sustavima, industrijskom hlađenju, kemijskoj obradi...
PROČITAJ VIŠE -
Vodič za prilagodbu OEM dobavljača inženjeringa hladnjača Kako raste potražnja za segmentiranim tržištima u inozemnoj industriji rashladnog lanca, mnogi dobavljači i trgovci inženjeringa za hladnjače imaju za cilj stvoriti vlastite ma...
PROČITAJ VIŠE
KONTAKTIRAJTE NAS
BRZI LINKOVI
PROIZVODI
KONTAKTNI PODACI
- E-pošta: [email protected]
- Telefon: +86-15258555916
- Adresa: 301 Punan Avenue, Pukou Street, Shengzhou City, Shaoxing City, Zhejiang Province.China
Autorsko pravo © Zhejiang Lanxi Refrigeration Equipment Co., Ltd. Sva prava pridržana.
浙ICP备2022034605号-1
Veletrgovina Hanbell jedinica za srednje do visoke temperature Tvornica
